Stable and reliable laser light source has an ultra-long service lifespan of 30,000 hours. It can save more than 30% of energy consumption and solve problem of lumen depreciation.
Three LCD chips work together to generate natural color optical system. For 3LCD technology, the color brightness equals to white brightness. There is no rainbow effect, and higher color restoration capability, which will produce more real and nature color.
BR-K1000 supports decoding 30Hz 4K signal and HDR for an ultra-high-resolution experience. The system also supports HDR (High Dynamic Range) and emulation for BT.2020, which reproduce a wider color range than conventional standards.
HDBaseT offers uncompressed HD multimedia content, including 4K resolution, through a single network cable of up to 100 m.
Equipped with 1.8x powered zoom standard len for great performance. It can easily project 100 inch big screen within the distance of 3.1 - 5.65m.
BRWall offers variety of optional projection lens in focal lengths ranging from short to long. The extensive line of optional lens can match different applications and needs.
Powered Lens Shift & Powered zoom and focus.
Featured both vertical/horizontal lens shift (vertical: ± 60%; horizontal: ±30%). Zoom and focus can operated by remote control, so the adjustment can be carried out from a distance.
This function is design for four screen corners and Horizontal / Vertical Corner Keystone Correction in order to adjustments for a distortion image.
Free 360° projector cabinet installation for fexible projection from almost any angle. It makes installation easier.
High-setting vertical and horizontal lenses’ optical shift function, which will not affect its picture quality. The projector can be installed or placed more easily and flexibly.
This function is design for four screen corners and Horizontal / Vertical Corner Keystone Correction in order to adjustments for a distortion image.
The built-in smart temperature control system can monitor the projector internal temperature in real time. It also smartly controls the fan speed to automatically adjust the projector’s working temperature, maintaining the projector in a good and constant temperature environment, which increases the projector’s stability and prolongs its service life.
Since the entire projector uses a fully-enclosed structure design, it can block dust from entering without the need of using a flter, thus prolonging the internal optical element’s service life. With the ingenious fully-enclosed internal circulating cooling system (ICCS), it can achieve high cooling performance ensuring that the projector is stable, significantly reducing maintenance cost, low consumables, environment-friendly and cost saving.
Product Model
|
BR-K1000 |
|---|---|
Display Technology
|
Liquid Crystal Display
|
LCD panel
|
3x0.64”(16:10)
|
Brightness Light |
10000 lm
|
Brightness Color Light
|
10000 lm
|
Resolution
|
WUXGA (1920x1200)
|
Number of pixels
|
6,912,000 pixels (1920 x 1200) x3 |
Contrast
|
3500000:1
|
Lens
|
F1.8~2.6，f=23.98~43.18mm，Manual zoom (1.8x)，Manual focus
|
Screen size
|
40”~300”
|
Throw distance
|
1.21m~17.04m
|
Throw Ratio
|
1.42~2.64 |
Light source (service life)
|
Laser diode (Normal mode: 25000h)
|
Lens Shift
|
Vertical: ±120% (Powered) Horizontal: ±60% (Powered)
|
Keystone Correction
|
Vertical: ±40º (Auto)，Horizontal: ±15º (Manual)
|
Input Terminals |
PC: VGA (D-sub 15pin) ×1 Audio: ( 3.5mm mini jack ) ×1 Video: DVI ×1，HDMI ×1，RGBHV / Component / Video ×1 (5BNC) Others: USB Type-A ×2，HDBaseT x 1，Remote(R/C in) x 1 |
Output terminal
|
VGA (D-sub 15pin) ×1，Audio: ( 3.5mm mini jack ) ×1，Remote(R/C out) x 1
|
Control terminal
|
RS232 (D-sub 9pin) ×1 ，RJ-45 ×1 (Control)，Remote x 1
|
PC input signal
|
PC-VGA, SVGA, XGA, SXGA, WXGA, UXGA, WSXGA, WUXGA, 4K(30Hz), Mac
|
Video input signal
|
PAL, NTSC, SECAM,(480i, 480p, 576i, 576p,720p,1080i,1080p)
|
Scanning Frequency
|
Horizontal: 15~90kHz，Vertical: 24~85Hz
|
Noise
|
42dB
|
Projection method
|
Ceiling/floor，front/rear |
Speaker
|
10W×1
|
Weight
|
23kg
|
Dimension (WxHxD)
|
645×210×440mm (not incl. protruded part)
|
Power supply
|
100~240V AC (50/60Hz)
|
Power Consumption
|
710W max (1W when Standby mode set to Eco)
|
Operating environment
| 0ºC~40ºC(Over35ºC go to ECO2 mode)
|
Operating Humidity | 20ºC~80ºC(non-condensation)
|
Standard accessory
|
Wireless remote control, power cord
|
*These specifications and the product’s design are subject to change without notice.
Screen size (inch) |
min. (wide) (meters) |
max.(tele) (meters) |
|---|---|---|
100“
|
3.10 |
5.65 |
120”
|
3.74 |
6.79 |
135“
|
4.21 |
7.64 |
150”
|
4.68 |
8.49 |
200”
|
6.26 |
11.34 |
240”
|
7.52 |
13.64 |
300”
|
9.41 |
17.04 |
400”
|
12.57 |
22.74 |
500”
|
15.72 |
28.44 |
Unit: mm
